SwitchingDiodes
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| Compliance (Only Automotive Supports PPAP) | Standard |
|---|---|
| AEC Qualified | No |
| Configuration | Single |
| Polarity | Anode, Cathode |
| ESD Diodes (Y|N) | No |
| Peak RepetitiveReverse VoltageVRRM (V) | 90 V |
| Reverse RecoveryTime trr (ns) | 4 ns |
| Trr(ns) Max @ IF=IR=10 mA, Irr=0.1xIR, RL=100Ω | 4 |
| V(BR)R (V) Min @IR=100μA | 90 |
| Maximum Average Rectifier Current IO (mA) | 100 mA |
| Maximum Peak Forward Surge Current IFSM (A) | 0.5 A |
| Forward Voltage Drop VF @ IF (mA) | 100 mA |
| Maximum ReverseCurrent IR (µA) | 0.1 µA |
| VF(V) Max @ IF=100mA | 1.2 |
| Maximum Reverse Current IR @ VR (V) | 80 V |
| IR(uA) Max @ VR=80V | 0.1uA@80V |
| CT(pF) Max @ VR = 0V, f = 1MHz | 3 |
