Image shown is for reference only. Actual package may vary. Refer to the product data sheet for package details. X3-DFN0603-2
Image shown is for reference only. Actual package may vary. Refer to the product data sheet for package details. X3-DFN0603-2
Image shown is for reference only. Actual package may vary. Refer to the product data sheet for package details. X3-DFN0603-2
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| Compliance (Only Automotive Supports PPAP) | Standard |
|---|---|
| Maximum Peak Pulse Current IPP @ 8x20µs Max | 6 |
| AEC Qualified | Yes |
| Configuration | Single (Bi-Directional) |
| Channel Input CapacitanceCT Typ (pF) | 15 pF |
| Reverse Standoff Voltage VRWM(V) | 5 V |
| Breakdown VoltageVBR Min(V) | 6 V |
| Typ Reverse Leakage Current IR @ VRWM Max(µA) | 0.01 µA |
| Maximum Clamping Voltage @ Max Peak Pulse Current VC (V) | 12 V |
| VESD IEC61000-4-2 Contact Discharge(kV) | 30 kV |
