ZXT2MA (Obsolete)

Inactive Datasheet Archive

Contact Sales

Log in or register to manage email notifications about changes to datasheets or PCNs for this part.

Application(s)

  • MOSFET Gate Driving
  • DC-DC Converters
  • Charging Circuits
  • Power switches
  • Motor Control
  • Product Specifications

    Product Parameters

    Compliance (Only Automotive supports PPAP) On Request*
    Category Low Saturation Transistor
    Compliance(Only Automotive supports PPAP) Catalog
    fT (MHz) 180
    fT (MHz) 180
    hFE (min) 300
    hFE(@ IC) 0.01
    hFE (@ IC) (A) 0.1
    hFE(@ IC2) 150
    hFE (@ IC2) (A) 2
    hFE(Min 2) 150
    hFE (Min) 300
    IC (A) 4
    IC (A) 4
    ICM (A) N/A
    ICM (A) 6
    PD (W) 2.45
    PD (W) 1.5
    Polarity PNP
    Product Type PNP
    AEC Qualified Yes
    RCE(SAT) N/A
    RCE(sat) (mΩ) 64
    VCE (SAT) (@ IC/IB) (A/m A) 1/10
    VCE (SAT) (@ IC/IB2) (A/mA) 2.5/150
    VCE (SAT)(Max.2) 250
    VCE (SAT)Max (mV) 30
    VCE(SAT) (@ IC/IB) (A/mA) 1/20
    VCE(sat) (@ IC/IB2) (A/mA) 2.5/150
    VCE(sat) (Max.2) (mV) 350
    VCE(sat) Max (mV) 220
    VCEO, VCES (V) 20
    VCEO, VCES (V) 20
