1500W Transient Voltage Suppressor
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| Compliance (Only Automotive supports PPAP) | Standard |
|---|---|
| BreakdownVoltageVBR Max (V) | 116 |
| Breakdown VoltageVBR Min(V) | 105 |
| Configuration | Single (Uni-Directional) |
| Maximum Clamping Voltage @ Max Peak Pulse Current VC (V) | 152 |
| Maximum Reverse Leakage CurrentIR @ VRWM Max (µA) | 5 |
| AEC Qualified | No |
| Reverse Standoff Voltage VRWM(V) | 94 |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2551 | 2021-11-10 | 2022-05-10 | Device End of Life (EOL) |
