| @ IF (A) | 6 |
|---|---|
| @ VR (V) | 100 |
| Compliance (Only Automotive supports PPAP) | No |
| Configuration | Single |
| Forward VoltageDrop VF(V) | 0.9 |
| MaximumAverageRectifiedCurrent IO (A) | 6 |
| Maximum ReverseCurrent IR (µA) | 10 |
| Peak ForwardSurge CurrentIFSM(A) | 400 |
| Peak RepetitiveReverse VoltageVRRM (V) | 100 |
| Product Type | 6A SILICON RECTIFIER |
| AEC Qualified | No |
| Reverse RecoveryTime trr (ns) | N/A |
| TotalCapacitance CT (pF) | N/A |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2453 | 2020-04-07 | 2020-10-07 | Device End of Life (EOL) |
