DUAL SURFACE MOUNT FAST SWITCHING DIODE
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| AEC Qualified | Yes |
|---|---|
| Compliance (Only Automotive supports PPAP) | Automotive |
| Configuration | Dual, Isolated |
| Polarity | Anode, Cathode |
| Power Rating(mW) | 250 mW |
| ESD Diodes (Y|N) | No |
| Peak RepetitiveReverse VoltageVRRM (V) | 85 V |
| Reverse RecoveryTime trr (ns) | 4 ns |
| Maximum Average Rectifier Current IO (mA) | 215 mA |
| Maximum Peak Forward Surge Current IFSM (A) | 4 A |
| Forward Voltage Drop VF @ IF (mA) | 0.715, 1 mA |
| Maximum ReverseCurrent IR (µA) | 1 µA |
| TotalCapacitance CT (pF) | 1.5 pF |
| VF(V) Max @ IF=100mA | 1 |
| V(BR)R (V) Min @IR=100μA | 85 |
| Trr(ns) Max @ IF=IR=10 mA, Irr=0.1xIR, RL=100Ω | 4 |
| Maximum Reverse Current IR @ VR (V) | 85 V |
| CT(pF) Max @ VR = 0V, f = 1MHz | 1.5 |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2462 | 2020-05-08 | 2021-04-11 | Phenitec Wafer Manufacturing Site Change, Additional Wafer Sources, Wafer Diameter Change, Additional Assembly and Test Site (Automotive) |
| PCN-2319 | 2018-03-09 | 2018-06-09 | Qualification of Alternative Wafer Sources for Select Automotive Products Due to Closure of Diodes FabTech (KFAB) Facility |
