SwitchingDiodes
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| AEC Qualified | No |
|---|---|
| Compliance (Only Automotive supports PPAP) | Standard |
| Configuration | Single |
| Polarity | Anode, Cathode |
| Power Rating(mW) | 250 mW |
| ESD Diodes (Y|N) | No |
| Peak RepetitiveReverse VoltageVRRM (V) | 250 V |
| Reverse RecoveryTime trr (ns) | 50 ns |
| Maximum Average Rectifier Current IO (mA) | 200 mA |
| Forward Voltage Drop VF @ IF (mA) | 200 mA |
| Maximum ReverseCurrent IR (µA) | 100 µA |
| VF(V) Max @ IF=100mA | 1.25 |
| V(BR)R (V) Min @IR=100μA | 250 |
| Trr(ns) Max @ IF=IR=10 mA, Irr=0.1xIR, RL=100Ω | 50 |
| Maximum Reverse Current IR @ VR (V) | 250 V |
| IR(uA) Max @ VR=80V | 0.1uA@200V |
| CT(pF) Max @ VR = 0V, f = 1MHz | 5 |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2607 | 2023-02-22 | 2023-08-22 | Device End of Life (EOL) |
