D15V0S1U2LP1608A

ONE CHANNEL HIGH SURGE TVS DIODE

Contact Sales

Provides ESD Protection per IEC 61000-4-2 Standard:
Air ±30kV, Contact ±30kV
One Channel of ESD Protection
Low Channel Input Capacitance
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
For automotive applications requiring specific change
control (i.e. parts qualified to AEC-Q100/101/200, PPAP
capable, and manufactured in IATF 16949 certified facilities),
please contact us or your local Diodes representative.
https://www.diodes.com/quality/product-definitions/

Product Specifications

Compliance (Only Automotive supports PPAP)	Standard
AEC Qualified	No
Configuration	Single (Uni-Directional)
Channel Input CapacitanceC_T Typ (pF)	264 pF
Reverse Standoff Voltage V_RWM_(V)	15 V
Breakdown VoltageV_BR Min(V)	17 V
Typ Reverse Leakage Current I_R @ V_{RWM Max}_(µA)	0.1 µA
Maximum Clamping Voltage @ Max Peak Pulse Current V_C _(V)	35 V
VESD IEC61000-4-2 Contact Discharge(kV)	30 kV
