4 CHANNEL LOW CAPACITANCE TVS DIODE ARRAY
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
This D3V3P4U10LP26 incorporates eight surge rated, low capacitance steering diodes and a TVS in a single package. During transient conditions, the steering diodes direct the transient to either the positive side of the power supply line or to ground. The D3V3P4U10LP26 may be used to meet the ESD immunity requirements of IEC 61000-4-2, Level 4 and IEC 61000-4-5. The TVS diodes provide effective suppression of ESD voltages: ±30 kV (air discharge) and ±30 kV (contact discharge).
| Compliance (Only Automotive supports PPAP) | Standard |
|---|---|
| Maximum Peak Pulse Current IPP @ 8x20µs Max | 25 |
| AEC Qualified | Yes |
| Configuration | Quad (Uni-Directional) |
| Channel Input CapacitanceCT Typ (pF) | 3.8 pF |
| Reverse Standoff Voltage VRWM(V) | 3.3 V |
| Breakdown VoltageVBR Min(V) | 3.8 V |
| Typ Reverse Leakage Current IR @ VRWM Max(µA) | 1 µA |
| Maximum Clamping Voltage @ Max Peak Pulse Current VC (V) | 12 V |
| VESD IEC61000-4-2 Contact Discharge(kV) | 30 kV |
