NRND = Not Recommended for New Design
standard rectifier
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| @ IF (A) | 1 |
|---|---|
| @ VR (V) | 600 |
| Compliance (Only Automotive supports PPAP) | Standard |
| Configuration | Single |
| Forward VoltageDrop VF(V) | 1 |
| MaximumAverageRectifiedCurrent IO (A) | 1 |
| Maximum ReverseCurrent IR (µA) | 5 |
| Peak ForwardSurge CurrentIFSM(A) | 30 |
| Peak RepetitiveReverse VoltageVRRM (V) | 600 |
| Product Type | 1A GLASS PASSIVATED RECTIFIER |
| AEC Qualified | No |
| Reverse RecoveryTime trr (ns) | 2000 |
| TotalCapacitance CT (pF) | 8 |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2631 | 2023-11-07 | 2024-02-07 | Transfer of Wafer Manufacturing Site for Select Discrete Products |
