bridge rectifier
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| AEC Qualified | No |
|---|---|
| Compliance (Only Automotive supports PPAP) | Standard |
| Forward VoltageDrop VF(V) | 1.1 |
| TotalCapacitance CT (pF) | 25 pF |
| MaximumAverageRectifiedCurrent IO (A) | 1.5 A |
| Peak RepetitiveReverse VoltageVRRM (V) | 400 V |
| Maximum Peak Forward Surge Current IFSM (A) | 50 A |
| Maximum ReverseCurrent IR (µA) | 10 µA |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2631 | 2023-11-07 | 2024-02-07 | Transfer of Wafer Manufacturing Site for Select Discrete Products |
