DMN10H220LPDW

N-CHANNEL ENHANCEMENT MODE MOSFET

Contact Sales

Log in or register to manage email notifications about changes to datasheets or PCNs for this part.

Specifications & Technical Documents

Product Parameters

AEC Qualified No
Compliance (Only Automotive(Q) supports PPAP) Standard
Polarity N+N
ESD Diodes (Y|N) No
|VDS| (V) 100 V
|VGS| (±V) 20 ±V
|IDS| @TC = +25°C (A) 8
PD @TA = +25°C (W) 2.2
RDS(ON)Max@ VGS(10V)(mΩ) 222 mΩ
RDS(ON)Max@ VGS(4.5V)(mΩ) 270 mΩ
|VGS(TH)| Max (V) 2.5 V
QG Typ @ |VGS| = 4.5V (nC) 3.7 nC
QG Typ @ |VGS| = 10V (nC) 6.7 nC
CISS Typ (pF) 384 pF
CISS Condition @|VDS| (V) 25 V

Technical Documents

SPICE Model

Recommended Soldering Techniques

TN1.pdf

RoHS CofC
