LZ52C5V6W(LS) (NRND)

NRND = Not Recommended for New Design

SURFACE MOUNT ZENER DIODE

Datasheet

Contact Sales

Description

SURFACE MOUNT ZENER DIODE

Feature(s)

For surface mounted application
Silicon epitaxial planar diode
Ultra small surface mount package
Low leakage current
2% tolerance device of Vz
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)

Product Specifications

Product Parameters

@ I_{ZT (mA)}	5
Compliance (Only Automotive supports PPAP)	Standard
Configuration	Single
I_{R (µA)}	0.1
Nom V_{Z (V)}	5.6
Power Rating(mW)	500
AEC Qualified	No
Tol V (Typ) (%)	2.14

Technical Documents

Recommended Soldering Techniques

TN1.pdf

Product Change Notices (PCNs)

A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.

PCN #	Issue Date	Implementation Date	Subject
PCN-2607	2023-02-22	2023-08-22	Device End of Life (EOL)
