This SCHOTTKY BARRIER RECTIFIER is designed to meet the stringent requirements of Commercial Applications.
| @ IF (A) | 5 |
|---|---|
| @ TerminalTemperature TT (ºC) | N/A |
| @ VR (V) | 200 |
| Compliance (Only Automotive supports PPAP) | No |
| Configuration | Single |
| Forward VoltageDrop VF(V) | 0.95 |
| MaximumAverageRectifiedCurrent IO (A) | 5 |
| Maximum ReverseCurrent IR (µA) | 500 |
| Peak ForwardSurge CurrentIFSM(A) | 100 |
| Peak RepetitiveReverse VoltageVRRM (V) | 200 |
| AEC Qualified | No |
| Reverse RecoveryTime trr (ns) | N/A |
| TotalCapacitance CT (pF) | N/A |
