D15V0M2U3SLP

2 Channels Unidirectional TVS Diode

Datasheet

Contact Sales

Description

This new generation TVS is designed to protect sensitive electronics from ESD and surge damages. The dual channels product with advantages of small size and high ESD surge capability is ideal for use in the Type-C CC protection for portable and computer applications.

Feature(s)

Two Channels of ESD and Surge Protection
Provides ESD Protection per IEC 61000-4-2 Standard: Air ±30kV, Contact ±30kV
Provides Surge and Lightning Protection per IEC 61000-4-5
Standard: I_PPMax 12A
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/104/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative. https://www.diodes.com/quality/product-definitions/

Application(s)

Cellular handsets
Portable electronics
Computers and peripherals
Type-C CC pin protections

Product Specifications

Product Parameters

Compliance (Only Automotive supports PPAP)	Standard
AEC Qualified	No
Configuration	Uni-Directional
Channel Input CapacitanceC_T Typ (pF)	64 pF
Reverse Standoff Voltage V_RWM_(V)	15 V
Breakdown VoltageV_BR Min(V)	15.5 V
Typ Reverse Leakage Current I_R @ V_{RWM Max}_(µA)	1 µA
VESD IEC61000-4-2 Contact Discharge(kV)	±30 kV
